FreeBSD14 ; FTP Server , Samba Fileserver

Contents

1. FTP Server(Vsftpd)
- 1.1 advance preparation
- 1.2 vsftpd Install
2. File Server with Samba

1. FTP Server(Vsftpd)

1.1 advance preparation

①Private Key Creation

# cd /etc/ssl
# openssl genrsa -des3 -out server.key 2048
Generating RSA private key, 2048 bit long modulus (2 primes)
.........................................................................................................................................+++++
.................................................+++++
e is 65537 (0x010001)
Enter pass phrase for server.key:
Verifying - Enter pass phrase for server.key:



Enter PEM pass phrase:
Verifying - Enter PEM pass phrase:

# cd /etc/ssl

# openssl genrsa -des3 -out server.key 2048

Generating RSA private key, 2048 bit long modulus (2 primes)

.........................................................................................................................................+++++

.................................................+++++

e is 65537 (0x010001)

Enter pass phrase for server.key:

Verifying - Enter pass phrase for server.key:

Enter PEM pass phrase:

Verifying - Enter PEM pass phrase:

➁Passphrase Deletion

# openssl rsa -in server.key -out server.key
Enter pass phrase for server.key: ←Enter the passphrase from earlier
writing RSA key

# openssl rsa -in server.key -out server.key

Enter pass phrase for server.key: ←Enter the passphrase from earlier

writing RSA key

➂change of access permission

# chmod 400 server.key

1	# chmod 400 server.key

④Self-certification

# cd /etc/ssl/
# openssl req -new -x509 -days 3650 -key server.key -out ftp.crt
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:JP　←country name
State or Province Name (full name) [Some-State]:Osaka　←prefecture name
Locality Name (eg, city) []:Sakai　←municipalities
Organization Name (eg, company) [Internet Widgits Pty Ltd]:Lepard　←Host name (or company name))
Organizational Unit Name (eg, section) []:　←Enter
Common Name (e.g. server FQDN or YOUR name) []:Admin　←Host name (or administrator name)
Email Address []:hoge@hoge.com　←Administrator's email address

# cd /etc/ssl/

# openssl req -new -x509 -days 3650 -key server.key -out ftp.crt

You are about to be asked to enter information that will be incorporated

into your certificate request.

What you are about to enter is what is called a Distinguished Name or a DN.

There are quite a few fields but you can leave some blank

For some fields there will be a default value,

If you enter '.', the field will be left blank.

-----

Country Name (2 letter code) [AU]:JP　←country name

State or Province Name (full name) [Some-State]:Osaka　←prefecture name

Locality Name (eg, city) []:Sakai　←municipalities

Organization Name (eg, company) [Internet Widgits Pty Ltd]:Lepard　←Host name (or company name))

Organizational Unit Name (eg, section) []:　←Enter

Common Name (e.g. server FQDN or YOUR name) []:Admin　←Host name (or administrator name)

Email Address []:hoge@hoge.com　←Administrator's email address

# cat server.key ftp.crt > ftp.pem
# chmod 400 ftp.*

1 2	# cat server.key ftp.crt > ftp.pem # chmod 400 ftp.*

1.2 vsftpd Install

1.1 Install

# cd /usr/ports/ftp/vsftpd
# make BATCH=yes WITH_VSFTPD_SSL=yes install clean

1 2	# cd /usr/ports/ftp/vsftpd # make BATCH=yes WITH_VSFTPD_SSL=yes install clean

1.2 Edit vsftpd configuration file

# chmod 640 /usr/local/etc/vsftpd.conf

# vi /usr/local/etc/vsftpd.conf
Per Line12
anonymous_enable=YES
↓
anonymous_enable=NO ←Change

Per Line 15
#local_enable=YES
↓
local_enable=YES ←Uncomment

Per Line18
#write_enable=YES
↓
write_enable=YES ←Uncomment

Per Line22
#local_umask=022
↓
local_umask=022 ←Uncomment

Per Line51
#xferlog_file=/var/log/vsftpd.log
↓
xferlog_file=/var/log/vsftpd.log ←Uncomment

Per Line 80
#ascii_upload_enable=YES
↓
ascii_upload_enable=YES ←Uncomment

Per Line81
#ascii_download_enable=YES
↓
ascii_download_enable=YES ←Uncomment

Per Line98
#chroot_local_user=YES
↓
chroot_local_user=YES ←Uncomment

Per Line99
#chroot_list_enable=YES
↓
chroot_list_enable=YES ←Uncomment

Per Line101
#chroot_list_file=/etc/vsftpd.chroot_list
↓
chroot_list_file=/etc/vsftpd.chroot_list ←Uncomment

Per Line107
#ls_recurse_enable=YES
↓
ls_recurse_enable=YES ←Uncomment

Per Line112
listen=YES　　　　←IPv4 enabled

Per Line134
background=YES　　←Uncomment

#Add the following to the last line
pasv_enable=YES
pasv_addr_resolve=YES
pasv_min_port=4000
pasv_max_port=4009
use_localtime=YES
ssl_enable=YES
rsa_cert_file=/etc/ssl/ftp.pem
require_ssl_reuse=NO
force_local_logins_ssl=NO
force_local_data_ssl=NO
force_dot_files=YES

# chmod 640 /usr/local/etc/vsftpd.conf

# vi /usr/local/etc/vsftpd.conf

Per Line12

anonymous_enable=YES

↓

anonymous_enable=NO ←Change

Per Line 15

#local_enable=YES

↓

local_enable=YES ←Uncomment

Per Line18

#write_enable=YES

↓

write_enable=YES ←Uncomment

Per Line22

#local_umask=022

↓

local_umask=022 ←Uncomment

Per Line51

#xferlog_file=/var/log/vsftpd.log

↓

xferlog_file=/var/log/vsftpd.log ←Uncomment

Per Line 80

#ascii_upload_enable=YES

↓

ascii_upload_enable=YES ←Uncomment

Per Line81

#ascii_download_enable=YES

↓

ascii_download_enable=YES ←Uncomment

Per Line98

#chroot_local_user=YES

↓

chroot_local_user=YES ←Uncomment

Per Line99

#chroot_list_enable=YES

↓

chroot_list_enable=YES ←Uncomment

Per Line101

#chroot_list_file=/etc/vsftpd.chroot_list

↓

chroot_list_file=/etc/vsftpd.chroot_list ←Uncomment

Per Line107

#ls_recurse_enable=YES

↓

ls_recurse_enable=YES ←Uncomment

Per Line112

listen=YES　　　　←IPv4 enabled

Per Line134

background=YES　　←Uncomment

#Add the following to the last line

pasv_enable=YES

pasv_addr_resolve=YES

pasv_min_port=4000

pasv_max_port=4009

use_localtime=YES

ssl_enable=YES

rsa_cert_file=/etc/ssl/ftp.pem

require_ssl_reuse=NO

force_local_logins_ssl=NO

force_local_data_ssl=NO

force_dot_files=YES

Edit /etc/hosts.allow

# echo "vsftpd: ALL" >> /etc/hosts.allow

1	# echo "vsftpd: ALL" >> /etc/hosts.allow

Edit chroot_list
This time wrote the general user huong

# echo huong >> /etc/vsftpd.chroot_list

1	# echo huong >> /etc/vsftpd.chroot_list

Auto Start Enabled

# vi /etc/rc.conf
vsftpd_enable="YES" ←add
# service vsftpd start

# vi /etc/rc.conf

vsftpd_enable="YES" ←add

# service vsftpd start

1.3Passive port opening with Firewall
Refer to the following page to open ports 4000-4009

FreeBSD14 ; Initial setup (Vim , SSH , firewall, NTP server)

1. Vim InstallInstall Vim, which you are familiar with as an editor, as follows# pkg install -y vimEdit the ".shrc" to make Vim available as the standard editor, and log in again to reflect the change.FreeBSD14 has sh as default shell.You can check the current SHELL with the following command

1.4 Connect with FileZilla

Password : General user huong password

2. File Server with Samba

Use Samba to build a file server for Windows and Mac file sharing

2.1 Samba Install

# cd /usr/ports/net/samba416/
# make config

1 2	# cd /usr/ports/net/samba416/ # make config

Remove the active directory relationships for ADS and AD_DC, as they will not be used this time.
LDAP is also removed because account management is not done through LDAP.
By default, Zeroconf Support is checked for AVAHI, but change it to MDNSRESPONDER

Other options installed by default

# make install clean

1	# make install clean

2.2 Samba Configuration

Create a new /usr/local/etc/smb4.conf

# cd /usr/local/etc/

# vi smb4.conf

[global]
dos charset = CP932　←Character encoding used for communication with Windows clients
unix charset = UTF-8　←Character encoding used by FreeBSD on the Samba server side
workgroup = WORKGROUP　←Match the workgroup name set on the Windows side.
server string = FreeBSD　←Any name
netbios name = freebsd　　←Any name
security = user

[share]
path = /home/share　←Path of the directory to be shared
create mask = 0770　←Permissions for files/directories created in shared directories
directory mask = 0770 ←Permissions for files/directories created in shared directories
guest only = No　←No guest users allowed
guest ok = No　　←No guest users allowed
browseable = No
read only = No　　←Shared directories are writable
writable = Yes　　←Shared directories are writable

# cd /usr/local/etc/

# vi smb4.conf

[global]

dos charset = CP932　←Character encoding used for communication with Windows clients

unix charset = UTF-8　←Character encoding used by FreeBSD on the Samba server side

workgroup = WORKGROUP　←Match the workgroup name set on the Windows side.

server string = FreeBSD　←Any name

netbios name = freebsd　　←Any name

security = user

[share]

path = /home/share　←Path of the directory to be shared

create mask = 0770　←Permissions for files/directories created in shared directories

directory mask = 0770 ←Permissions for files/directories created in shared directories

guest only = No　←No guest users allowed

guest ok = No　　←No guest users allowed

browseable = No

read only = No　　←Shared directories are writable

writable = Yes　　←Shared directories are writable

Create shared directory
Set the shared directory as /home/share, the owner as huong (a general user registered in Freebsd), and the access permissions as read/write/execute for general users and the wheel group

# mkdir /home/share
# chown huong:wheel /home/share
# chmod -R 0770 /home/share

# mkdir /home/share

# chown huong:wheel /home/share

# chmod -R 0770 /home/share

Open /etc/rc.conf and add samba_server_enable="YES

# pdbedit -a -u huong
new password: Password
retype new password: again Password

# pdbedit -a -u huong

new password: Password

retype new password: again Password

If firewall is enabled, open samba use port (445)
xxx should be different from other rule numbers.

# vi /usr/local/etc/ipfw.rules
Add the following
$IPF xxx allow tcp from any to any 445 in
$IPF xxx allow tcp from any to any 445 out

system reboot
# shutdown -r now

# vi /usr/local/etc/ipfw.rules

Add the following

$IPF xxx allow tcp from any to any 445 in

$IPF xxx allow tcp from any to any 445 out

system reboot

# shutdown -r now

Start samba

# service samba_server start
Performing sanity check on Samba configuration: OK
Starting nmbd.
Starting smbd.

# service samba_server start

Performing sanity check on Samba configuration: OK

Starting nmbd.

Starting smbd.

2.3 Confirmation of Samba startup

Windows Settings
・Confirm that the workgroup name is "WORKGROUP

In the File Explorer address bar, type "\\<Samba Server IP address>\<shared directory name>".
(This time '\\192.168.11.83\share')
Enter your registered user name and password when the login screen appears.
